XRPKS-1 Mechanical Powder Compacting Press(for large quantities · simple structures)
Features1. Proprietary Technology
Fully enclosed self-lubrication system with internal pressure circulation and NOK dust seals for clean, low-maintenance operation.
Industry-leading productivity, delivering over 30% higher output than other mechanical powder presses.
2. High Efficiency & Precision
Pneumatic clutch and brake system with fast response and ±0.5° stopping accuracy.
Floating intermediate die with fixed ejection position, enabling three-step segmented density control.
3. User-Friendly Operation
Touch-screen control with real-time machine status monitoring.
Automatic fault detection, pressure monitoring, and adjustable dwell function.
4. High Quality
Heavy-duty frame and gearboxes integrally cast from nodular cast iron.
Induction-hardened guide pillars (HRC 60+) with hard chrome plating and phosphor bronze guide bushings.
Bottom-mounted drive system for quiet, low-vibration operation.
All components from globally recognized brand: Mitsubishi(PLC& VFD), Panasonic(servo motor), SMC&AIRTAC(all pneumatic parts), Omron & Schneider & Siemens(all electrical parts).
5. Optional
Automatic tray handling system.
Why XIRO machinery ?
Excellent Technology: The first company in China to develop a fully enclosed lubrication system and pioneer the application of servo technology in mechanical presses, with multiple patented core designs.
Direct Sales from the Source Manufacturer: With over 10 years of manufacturing experience, our machinery has been exported to more than 60 countries. We offer a comprehensive pre-sale and after-sale service system.
Service and Support: Professional engineering team offering 24/7 online technical service and response. With thousands of product cases, we assist you every step of the way, from process experience and technical solutions to installation, machine operation, and equipment maintenance, ensuring worry-free production for you!
Quality Assurance: We select globally renowned quality components to create durable and cost-effective machinery. All machines are ISO and CE certified, with a 2-year warranty and lifetime service. Longer warranty period than the same industry.
Click Contact Us submit your Information or send an email to sales@xirotech.cn
Bookmark our page. Learn more about the details of mechanical powder compacting press. Quality Machinery, Limited-Time Discount, Act Now, Don't Miss Out!
SpecificationThis table only lists partial parameter configurations for reference. For more parameter configurations, please feel free to inquire.
Type | 20T | 40T | ||
Maximum Compaction Force | 200 kN | 400 kN | ||
Ejection Force | 100 kN | 300 kN | ||
Die (Middle Die) Load Capacity | 150 kN | 300 kN | ||
Upper Punch Stroke | 90 mm | 130 mm | ||
Upper Punch Adjustment Range | 40 mm | 60 mm | ||
Fill Depth | 45 mm | 65 mm | ||
Ejection Stroke | 30 mm | 55 mm | ||
Powder Feed Adjustment Stroke | 5 mm | 5 mm | ||
Middle die face adjustment range | ±10 mm | ±10 mm | ||
Die Set Accuracy | Platen parallelism and guide pillar perpendicularity within 0.01 mm | |||
Forming Speed | 12–45 SPM | 6–50 SPM | ||
Overload / Underload Protection | Hydraulic load cell | |||
Clutch System | Pneumatic clutch–brake combination | |||
Lubrication Method | Internal circulating pressure lubrication | |||
Powder Feeding System | Cam-driven linear feed | |||
Powder Hopper Capacity | 10 L | 30 L | ||
Angle Controller | Encoder 360 | Encoder 360 (accuracy ±5°) | ||
Operation Modes | Jog, Continuous, Stop, Emergency Stop, Reverse, Powder Detection Switch, Production Counter, Production Ratio Counter, Pressure Monitoring Switch | |||
Main Motor Power | 4 kW | 7.5 kW | ||
Air Consumption | 15 L/min (Upper-1 / Lower-2 full functions enabled) | 20 L/min (all functions enabled) | ||
Power Supply | 380 V @ 50 Hz (or as customer request) | |||
Control Voltage | DC 24 V | |||
Tooling Structure | Upper-1 / Lower-1, Upper-1 / Lower-2 | Upper-1 / Lower-1 | ||
Floating Core Rod | Included | |||
Machine Weight | Approx. 2.0 T | Approx. 4 T | ||
Overall Dimensions (W × D × H) | 1400 × 860 × 2205 mm | 1570 × 1000 × 2850 mm | ||
Die Set Specifications (Upper-1 / Lower-1 Configuration) | Upper Punch Load Capacity | 200 kN | Upper Punch Load Capacity | 400 kN |
Die (Middle Die) Load Capacity | 150 kN | Die (Middle Die) Load Capacity | 300 kN | |
First Lower Punch Load Capacity | 150 kN | Lower Punch Load Capacity | 400 kN | |
Fixed Lower Punch Load Capacity | 200 kN | Core Rod Load Capacity | 100 kN | |
First Lower Punch Fill Adjustment | 30 mm | Movable Core Rod Fill Adjustment | 25 mm | |
First Lower Punch Step Height Adjustment | 15 mm | Movable Core Rod Step Height Adjustment | 15 mm | |
First Lower Punch Die Face Adjustment | ±5 mm | Floating Core Rod Stroke | 45 mm | |
Movable Core Rod Adjustment | ±5 mm | Weight | Approx. 200 kg | |
Floating Core Rod Stroke | 35 mm | |||
Weight | Approx. 130 kg | |||
